Cleveland, Ohio

Trinity Episcopal Cathedral

Trinity Episcopal Cathedral (Cleveland, OH)

Edwin Arthur Kraft at Ernest M. Skinner organ, Op. 140 (1906) in Trinity Episcopal Cathedral (Cleveland, OH)






Builder:        The Ernest M. Skinner Co.
   Year:        1906
   Opus:        140

No. manuals:    4
No. stops:      78
No. ranks:      41
No. pipes:      2,832

Specification

            GREAT ORGAN                               SWELL ORGAN
        16' Bourdon              61               16' Bourdon              73
         8' Philomela            61                8' First Diapason       73
         8' First Diapason       61                8' Second Diapason      CH
         8' Second Diapason      61                8' Geigen Principal     73
         8' Gross Floete         61                8' Clarabella           73
         8' Erzähler             61                8' Concert Flute        CH
         4' Principal            61                8' Spitzflöte           73
         4' Harmonic Flute       61                8' Gedackt              73
        16' Ophicleide           SO                8' Salicional           73
        16' Euphonium            12 *              8' Voix Celestes        73
         8' Tuba                 SO                8' Aeoline              CH
         8' Horn                 61 *              8' Dulcet II            CH
         4' First Clarion        SO                4' Flute                73
         4' Second Clarion       12 *              2' Piccolo              61
                                                 III  Mixture             183
            CHOIR ORGAN                           16' Trumpet              73
        16' Gamba                73                8' Cornopean            73
         8' Diapason             73                8' Oboe                 73
         8' Philomela            SO                4' Clarion              73
         8' Concert Flute        73                   Tremolo
         8' Quintadena           73
         8' Aeoline              73                   PEDAL ORGAN
         8' Unda Maris (TC)      61               32' Diapason             32
         8' Dulcet II           146               32' Resultant            --
         4' Flute Traverso       73               16' Diapason             12
       III  Mixture             183               16' Violone              32
         8' Tuba                 SO               16' First Bourdon        32
         8' Clarinet             73               16' Second Bourdon       SW
         8' Orchestral Oboe      73               16' Gamba                CH
         8' Vox Humana           73           10 2/3' Quinte               --
            Tremolo                                8' Octave               12
         8' Harp (TC)            49 bars           8' Gedackt              12
                                                   8' Cello                SW
            SOLO ORGAN                            16' Ophicleide           SO
         8' Philomela            17 PED           16' Euphonium            NV
         8' Flute                61                8' Tuba                 SO
         8' Quintadena           CH                8' Horn                 NV
         4' Flute                61                4' First Clarion        SO
         4' Flute Traverso       CH                4' Second Clarion       NV
        16' Ophicleide           12
        16' Euphonium            NV
         8' Harmonic Tuba        61
         8' Clarinet             CH
         8' Orchestral Oboe      CH
         8' Vox Humana           CH
         4' Clarion              12
         4' Second Clarion       NV

         *  in rear of nave under the floor, enclosed


Source: Schantz Organ Co. via Jonathan Bowen; corrected by Allen Kinzey according to factory specs.

Photo Source: OHS Archives, via Jonathan Bowen. (Photo #3: Edwin Kraft at the original Trinity console.)

Notes: The organ was rebuilt by Schantz as Op. 295 in 1956 with a new console using the existing shell. A new two-manual Flentrop choir organ was installed in 1976 and a 3-manual Flentrop was installed in the gallery in 1977. In 1977, the main chambers were sealed and, in 1998, the Skinner/Schantz was removed and parted out.

Organ Historical Society Database: https://pipeorgandatabase.org/OrganDetails.php?OrganID=5239
